IRAYUSA Micro RL25V2 Thermal 384×288 IRAY-RL25V2
| Device Technology: | Thermal Imaging |
| Sensor Resolution: | 384×288 |
| Sensor Frame Rate: | 50hz |
| Sensor Pixel Size: | 12μm |
| Optical Magnification: | 2X |
| Digital Magnification: | 4X |
| Detection Range: | 1375 Yards |
| Objective Focal Length: | 25mm f/1.0 |
| Objective Diameter: | 25mm |
| Objective F#: | 1.0 |
| Onboard Recording: | Video and Image |
IRAYUSA Micro RL25V2 Thermal 384×288 IRAY-RL25V2
The RICO MICRO Series is an advanced electro-optic device miniaturized to deliver remarkably versatile functionality: Handheld, helmet mount, and weapon mount. Weighing less than a pound, the MICRO will fit in the palm of your hand and can be used with standard dovetail helmet mounts or rifle-mounted as a stand-alone weapon sight. InfiRayOutdoor is blazing a new trail with features never-before-seen in a helmet-mounted thermal, such as onboard recording, onboard video play-back, and a high definition AMOLED display. The RL25 also features InfiRay’s latest high-performance 384×288, 12 μm sensor technology, MATRIX III processing, and a manual-focus f/1.0 objective lens to create an image that is unlike anything in its class.
Optics
- Optical Magnification
- 2X
- Digital Magnification
- 4X
- Objective Lens Material
- Germanium
- Horizontal Angular Field of View
- 10.5°
- Vertical Angular Field of View
- 7.9°
- Detection Range
- 1375 Yards
- Objective Focal Length
- 25mm f/1.0
- Objective Diameter
- 25mm
- Objective F#
- 1.0
- Focusing Mechanism
- Manual Focus
- Eye Relief
- 35mm
- Display Type
- AMOLED
- Diopter Range
- -4 – +4
- Display Resolution
- 1024×768
Features & Performance
- Reticle
- 7
- Connector Type
- "Data Cable with USB, BNC, and 7-Pin Connectors"
- Color Palettes
- White Hot, Black Hot, Red Hot, Color
- User-Updatable Firmware
- Yes
- Mobile App
- Yes
- Storage Capacity
- 64gb
- Connector Output
- Analog
- Picture-in-Picture
- No
- One-Shot Zero
- No
- Stand-by Mode
- Yes
- Rangefinder
- No
- Run Time
- 4 Hours
- Power Source
- 18650 Rechargeable
- Wifi
- Yes
- Onboard Recording
- Video and Image
- Image Capture
- Yes
- Video Output
- Analog RS-170/NTSC
- Startup Time
- <10 Seconds, Instant from Standby
- External Power Source
- Yes, 7-Pin to USB 5V
- Warranty
- 5 Years
- Country of Manufacture
- China
Environmental Specifications
- Operating Temperature Range
- -4°F to 122°F
- Recoil Rating
- 1000 g/s² (300 Win./7mm Mag)
- Ingress Protection
- IP67
Physical
- Mounting Interface
- MUM rail/Picatinny STD-1913 rail, PICTAIL optional
- Housing Material
- Aluminum
- Length
- 4.52 in
- Height
- 2.55 in
- Width
- 1.88 in
- Weight
- 12.7 oz
Sensor Specifications
- Device Technology
- Thermal Imaging
- Sensor Type
- InfiRay MICRO II
- Sensor Resolution
- 384×288
- Non-Uniformity Correction (NUC)
- Manual, Automatic, Semi-Automatic
- Spectral Response
- 8-12 Microns
- Sensor Frame Rate
- 50hz
- Sensor Pixel Size
- 12μm
- Thermal Sensitivity
- <50mk
